Side Mounted Magnetic Float Switch

Made in India 100% Tested & Calibrated

Model: HFLS-1600L

The HFLS-1600L is a horizontal side-mounted magnetic float switch featuring glandless magnetic coupling for liquid tanks, boilers, and lubricating reservoirs. The magnetic coupling completely isolates process fluid from the electrical switch compartment.

Side-Wall Tank Mounting Glandless Magnetic Coupling (Leak-Proof) Boilers & High Pressure Tanks High Reliability

Request Fast Quote Catalog Manual

Applications & Suitability

Boiler Water Level: High and low water alarm in steam boilers and condensate tanks.

Fuel & Lube Oil Tanks: Reliable level switching in oil reservoirs.

Chemical Process Vessels: Leak-proof level control in pressurized chemical vessels.

The HFLS-1600L is a reliable, maintenance-free level measurement solution for industrial process automation.

Model	HFLS-1600L
Application Media	Boiler Water, Oils, Fuels, Chemicals, Condensate
Mounting	Horizontal Side-Mounted Flanged / Threaded
Switch Output	1 SPDT / DPDT Microswitch (5A @ 230V AC)
Process Temperature	-20°C to +250°C
Process Pressure	Up to 25 Bar
Wetted Parts	Stainless Steel SS316
Enclosure	Cast Aluminium IP66 / Flameproof Exd IIB+H2 / IIC T6
